Monitor my network connection with go?

I often get the feeling that my network is acting slow on purpose. Often pages are stuck loading, seemingly without reason, and when I start up a ping, there is nothing wrong. Continuing to resolve the troublesome domain progresses me no further and when I more move back to the browser tab, everything seems fine again..

Grab your tinfoils and let’s get to the bottom of this conspiracy! (we shall at least try)

• Getting all the moving part working
  • Creating my first go script
  • Set variables for the script to use
• Setting up SQL for persistent storage
  • Create DB and assign permissions
• Setup crontab for regular script execution
• Query the data
• Conclusion

---

This is really just an excuse to finally code something in go (even though GitHub copilot did mostall of the heavy lifting) and get some more use out of the MariaDB.

---

Getting all the moving part working

1. Install go (duh!)
2. Setup the go project go mod init github.com/thorn5011/netMon
3. Install any dependencies go mod tidy (after adding imports to the code)
   1. This is a reaaally good feature where you lock down the dependencies with the correspiding hash in go.sum, ex. github.com/go-sql-driver/mysql v1.8.1 h1:LedoTUt/eveggdHS9qUFC1EFSa8bU2+1pZjSRpvNJ1Y=. No worrying about dependency confusion
4. Run script with go run script.go
   1. You can also build the project into an executable, but I won’t bother with that for now.

Creating my first go script

I simply want a script to loop through a few different DNS servers and resolve a couple of hostnames, while measuring the resolve time. Then we can graph it over time and look for anomalies.

The script scan be found here.

Learnt to code some very simple go, with arguments, different outputs and a bunch of troubleshooting.

Set variables for the script to use

Set variables in Windows:

setx NETMON_DB_USERNAME netMon_user /m
setx NETMON_DB_PASSWORD KEY /m

In Linux:

export NETMON_DB_USERNAME=netMon_user
export NETMON_DB_PASSWORD=KEY

---

Setting up SQL for persistent storage

Create DB and assign permissions

CREATE DATABASE netMon;
CREATE USER 'netMon_user'@'192.168.0.96' IDENTIFIED BY 'KEY';
GRANT CREATE, SELECT, INSERT ON netMon.* TO 'netMon_user'@'192.168.0.96';
-- show permissions
SHOW GRANTS FOR 'netMon_user'@'192.168.0.96';

---

Setup crontab for regular script execution

Environment variables are stored in /root/.envs and imported at crontab execution:

*/5 * * * * . /root/.envs && cd PATH/netMon/startMonitor && /usr/local/go/bin/go run PATH/netMon/startMonitor/netMon.go >> PATH/netMon/startMonitor/app.log

---

Query the data

-- count all rows
select COUNT(*) from dns_results;

-- show rows
select *
from dns_results
limit 5;

+----+------------+------------+---------------+---------------------+
| id | server     | hostname   | response_time | timestamp           |
+----+------------+------------+---------------+---------------------+
|  1 | 8.8.8.8:53 | google.com |            35 | 2024-09-02 17:15:36 |
|  2 | 8.8.8.8:53 | vg.no      |            17 | 2024-09-02 17:15:36 |
|  3 | 8.8.8.8:53 | vipps.no   |            23 | 2024-09-02 17:15:36 |
|  4 | 1.1.1.1:53 | google.com |             4 | 2024-09-02 17:15:36 |
|  5 | 1.1.1.1:53 | vg.no      |            24 | 2024-09-02 17:15:36 |
+----+------------+------------+---------------+---------------------+

Checking average response times

-- per server and hostname
SELECT server,hostname, AVG(response_time) AS avg_response_time
FROM dns_results
GROUP BY hostname,server;

-- per server
SELECT server, AVG(response_time) AS avg_response_time
FROM dns_results
GROUP BY server;

+----------------+-------------------+
| server         | avg_response_time |
+----------------+-------------------+
| 1.1.1.1        |           34.2612 |
| 192.168.0.1    |           26.3343 |
| 192.168.0.187  |           66.8090 |
| 8.8.8.8        |           43.2505 |
+----------------+-------------------+

So far the local router is in the lead and the Pi-hole is sadly at the back of the back.

Slow responses:

SELECT server,hostname,response_time,timestamp
FROM dns_results
ORDER BY response_time desc
LIMIT 5;


SELECT COUNT(*), server
FROM dns_results
WHERE response_time > 250
GROUP BY server;

+----------+----------------+
| COUNT(*) | server         |
+----------+----------------+
|       14 | 1.1.1.1        |
|        7 | 192.168.0.1    |
|       12 | 192.168.0.187  |
|        5 | 8.8.8.8        |
+----------+----------------+

I do want to graph this data out over time, but for that I need more tools.

---

Conclusion

There is much to learn from go, but I would bet that most, if not all use cases could be dealt with by Python. But having a rudimental understanding of a popular language such as go is useful (especially since go is one of the go-to languages we use)

I want to better understand the network data, so I think I’ll look into Metabase or redash to visualize it all, but we’ll see.
